Explain that Q-Learning Code!
Pairs
"Oh Gosh, Jeez. I deleted all the explanation. Could...could you help me out?"
With this assignment, you have to fill in the missing information and explanation. This assignment has a few goals:
- Give you a veiw of what the code for a Q-Learning Agent in an environment could look like.
- Give you an opportunity to explain things in your own words (and get help when you can't explain it or don't understand it)
- Give you an opportunity to be creative in the way you explain things and how you break the code down.
The task
Your task is to make your own explanation of the code using markdown. See here for an example of how I've chosen to explain a concept. Once you complete this assignment, upload the markdown and html to the Google classroom sight. There are several ways to convery markdown to something like HTML or a PDF. Ask me if you want pointers.
You should feel free to pull out lines of code, change comments to suit your way of explaining, etc.
The Code
From the RLAgents.py file
import malmoenv
import json
import logging
import math
import os
import random
import sys
import time
if sys.version_info[0] == 2:
import Tkinter as tk
else:
import tkinter as tk
class TDAgent:
""" Tabular Temporal-Difference Agent for Discrete State Spaces """
SCALE = 20
WORLD_X = 5
WORLD_Y = 5
def __init__(self, actions=[], alpha=0.1, gamma=1.0, debug=False, canvas=None, root=None):
self.alpha = alpha
self.gamma = gamma
self.training = True
self.actions = actions
self.u_table = {}
self.canvas = canvas
self.root = root
self.rep = 0
def get_actions(self):
return (self.actions)
class QLAgent(TDAgent):
"""Tabular Q-learning agent for discrete state/action spaces."""
SCALE = 50
WORLD_X = 5
WORLD_Y = 5
def __init__(self, actions=[], epsilon=0.1, alpha=0.1, gamma=1.0, debug=False, canvas=None, root=None,seed=5):
super(QLAgent, self).__init__(actions, alpha, gamma, debug, canvas, root)
self.epsilon = epsilon
self.q_table = self.u_table
self.rnd = random.Random()
self.rnd.seed(5)
def load_model(self, model_file):
"""load q table from model_file"""
with open(model_file) as f:
self.q_table = json.load(f)
def training(self):
"""switch to training mode"""
self.training = True
def evaluate(self):
"""switch to evaluation mode (no training)"""
self.training = False
def act(self, env, info_json, current_r ):
"""take action in response to the current world state"""
curr_x = int(info_json[u'XPos'])
curr_z = int(info_json[u'ZPos'])
current_s = "%d:%d" % (curr_x, curr_z)
if (not (current_s in self.q_table)):
self.q_table[current_s] = ([0] * len(self.actions))
#
if (self.training):
self._learn(current_r, True, current_s)
self.draw_q(curr_x = curr_x, curr_y = curr_z)
#
rnd_num = self.rnd.random()
if rnd_num < self.epsilon:
a = self.rnd.randint(0, len(self.actions) - 1)
else:
#
m = max(self.q_table[current_s])
l = list()
for x in range(0, len(self.actions)):
if self.q_table[current_s][x] == m:
l.append(x)
#
y = self.rnd.randint(0, len(l)-1)
a = l[y]
#
(obs, reward, sim_done, info) = env.step(a)
time.sleep(0.01)
self.prev_s = current_s
self.prev_a = a
return (reward, sim_done, info)
def run(self, env, info, reward):
"""run the agent on the world"""
total_reward = 0
current_r = reward
tol = 0.01
self.prev_s = None
self.prev_a = None
while (info is None or len(info) == 0):
(obs, current_r, sim_done, info) = env.step(4)
time.sleep(0.01)
info_json = json.loads(info)
prev_x = int(info_json[u'XPos'])
prev_z = int(info_json[u'ZPos'])
# get some info from an initial action
(current_r, sim_done, info) = self.act(env, info_json, current_r)
total_reward += current_r
require_move = True
check_expected_position = True
while not sim_done:
#--- Wait for some info ---#
if (info is None or len(info) == 0):
(obs, current_r, sim_done, info) = env.step(4)
time.sleep(0.01)
#--- We received info, so continue on ---#
else:
# Get our position
info_json = json.loads(info)
curr_x = int(info_json[u'XPos'])
curr_z = int(info_json[u'ZPos'])
#--- We seem to run into an issue where the simulation isn't marked as done & we need to query again. ---#
(obs, current_r, sim_done, info) = env.step(4)
time.sleep(0.01)
print(info)
#------#
###--- If the simulation has completed, make sure we can assign a value to the action we completed from our current state
if (sim_done):
self.prev_s = "%d:%d" % (int(curr_x), int(curr_z))
if (not (self.prev_s in self.q_table)):
self.q_table[self.prev_s] = ([0] * len(self.actions))
break
#------#
#--- Check to see if the movement has been observed ---#
# Checks for an expected move that hasn't yet been represented on the information we've gotten back
# (and pings the server for the correct info)
expected_x = prev_x + [0,0,-1,1][self.prev_a]
expected_z = prev_z + [-1,1,0,0][self.prev_a]
while (math.hypot( curr_x - expected_x, curr_z - expected_z ) > 0.01 and (not sim_done)):
#print(' - ERROR DETECTED! Expected:',expected_x,',',expected_z)
(obs, current_r, sim_done, info) = env.step(4)
while ((info is None or len(info) == 0) and (not sim_done)):
(obs, current_r, sim_done, info) = env.step(4)
time.sleep(0.01)
# Case where we might have finished the sim, but not gotten actual info back
if (sim_done):
self.prev_s = "%d:%d" % (int(curr_x), int(curr_z))
if (not (self.prev_s in self.q_table)):
self.q_table[self.prev_s] = ([0] * len(self.actions))
break
info_json = json.loads(info)
curr_x = int(info_json[u'XPos'])
curr_z = int(info_json[u'ZPos'])
#------#
#--- If the simulation has completed, make sure we can assign a value to the action we completed from our current state ---#
if (sim_done):
self.prev_s = "%d:%d" % (int(curr_x), int(curr_z))
if (not (self.prev_s in self.q_table)):
self.q_table[self.prev_s] = ([0] * len(self.actions))
break
#------#
prev_x = curr_x
prev_z = curr_z
# act
(current_r, sim_done, info) = self.act(env, info_json, current_r)
total_reward += current_r
#--- Beceause we use the maze decorator...the correct reward isn't given on the final block...
# so we adjust for this by knowing that if it isn't a negative reward...we must have ended on the goal block. ---#
if (current_r > 0):
current_r = 100
#------#
#
print("Final reward: %d" % current_r)
print("Final Position: %d : %d" % (curr_x, curr_z))
#
if (self.training):
self._learn(current_r, True)
self.draw_q(curr_x = int(curr_x), curr_y = int(curr_z))
return total_reward
def _learn(self, reward, terminal_state=True, current_s=None):
"""
The equation to learn in Q-learning
q(s,a,t+1) = q(s,a,t) + alpha * (reward + gamma * max(q(s') - q(s,a,t))
"""
if (terminal_state):
if (self.prev_s is not None and self.prev_a is not None):
old_q = self.q_table[self.prev_s][self.prev_a]
self.q_table[self.prev_s][self.prev_a] = old_q + self.alpha * ( reward - old_q )
else:
if (current_s is None):
print("Can't learn without knowing your current state!")
return
old_q = self.q_table[self.prev_s][self.prev_a]
self.q_table[self.prev_s][self.prev_a] = old_q + self.alpha * \
(reward + self.gamma * max(self.q_table[current_s]) - old_q)
def draw_q( self, curr_x=None, curr_y=None ):
if self.canvas is None or self.root is None:
return
self.canvas.delete("all")
action_inset = 0.1
action_radius = 0.1
curr_radius = 0.2
action_positions = [ ( 0.5, 1-action_inset ), ( 0.5, action_inset ), ( 1-action_inset, 0.5 ), ( action_inset, 0.5 ) ]
# (NSWE to match action order)
min_value = -100
max_value = 100
for x in range(QLAgent.WORLD_X):
for y in range(QLAgent.WORLD_Y):
s = "%d:%d" % (x,y)
self.canvas.create_rectangle( (QLAgent.WORLD_X-1-x)*QLAgent.SCALE, (QLAgent.WORLD_Y-1-y)*QLAgent.SCALE, (QLAgent.WORLD_X-1-x+1)*QLAgent.SCALE, (QLAgent.WORLD_Y-1-y+1)*QLAgent.SCALE, outline="#fff", fill="#000")
for action in range(4):
if not s in self.q_table:
continue
value = self.q_table[s][action]
#print(value)
color = 255 * ( value - min_value ) / ( max_value - min_value ) # map value to 0-255
color = math.ceil(max(min(color, 255),0)) # ensure within [0,255] & integer
color_string = '#%02x%02x%02x' % (255-color, 0, color)
self.canvas.create_oval( (QLAgent.WORLD_X - 1 - x + action_positions[action][0] - action_radius ) *QLAgent.SCALE,
(QLAgent.WORLD_Y - 1 - y + action_positions[action][1] - action_radius ) *QLAgent.SCALE,
(QLAgent.WORLD_X - 1 - x + action_positions[action][0] + action_radius ) *QLAgent.SCALE,
(QLAgent.WORLD_Y - 1 - y + action_positions[action][1] + action_radius ) *QLAgent.SCALE,
outline=color_string, fill=color_string )
if curr_x is not None and curr_y is not None:
self.canvas.create_oval( (QLAgent.WORLD_X - 1 - curr_x + 0.5 - curr_radius ) * QLAgent.SCALE,
(QLAgent.WORLD_Y - 1 - curr_y + 0.5 - curr_radius ) * QLAgent.SCALE,
(QLAgent.WORLD_X - 1 - curr_x + 0.5 + curr_radius ) * QLAgent.SCALE,
(QLAgent.WORLD_Y - 1 - curr_y + 0.5 + curr_radius ) * QLAgent.SCALE,
outline="#fff", fill="#fff" )
self.root.update()
From the Main File (MazeSimRL.py)
# ------------------------------------------------------------------------------------------------
# Copyright (c) 2016 Microsoft Corporation
#
# Permission is hereby granted, free of charge, to any person obtaining a copy of this software and
# associated documentation files (the "Software"), to deal in the Software without restriction,
# including without limitation the rights to use, copy, modify, merge, publish, distribute,
# sublicense, and/or sell copies of the Software, and to permit persons to whom the Software is
# furnished to do so, subject to the following conditions:
#
# The above copyright notice and this permission notice shall be included in all copies or
# substantial portions of the Software.
#
# THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT
# NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND
# NONINFRINGEMENT. IN NO EVENT SHALL THE AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM,
# DAMAGES OR OTHER LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
# OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE SOFTWARE.
# ------------------------------------------------------------------------------------------------
# Dancy Oct-2019
# Can't seem to get the agent to actually reach the terminal/endblock
# (it seems to only get to the block before?) so unable to get the actual reward!
import malmoenv
import json
import math
import os
import random
import sys, argparse
import time
from RLAgents import *
import errno
if sys.version_info[0] == 2:
import Tkinter as tk
else:
import tkinter as tk
save_images = False
if save_images:
from PIL import Image
class MazeSimRL:
MAP_SIZE = 6
MS_PER_TICK = 5
FLOOR_BLOCK = "sandstone"
GAP_BLOCK = "lava"
PATH_BLOCK = "stone"
START_BLOCK = "emerald_block"
END_BLOCK = "diamond_block"
GOAL_BLOCK = "gold_block"
DEFAULT_MAZE = '''
<MazeDecorator>
<SizeAndPosition length="''' + str(MAP_SIZE-1) + '''"\
width="''' + str(MAP_SIZE-1) + '''" \
yOrigin="225" zOrigin="0" height="180"/>
<GapProbability variance="0.4">0.1</GapProbability>
<Seed>10</Seed>
<MaterialSeed>random</MaterialSeed>
<AllowDiagonalMovement>false</AllowDiagonalMovement>
<StartBlock fixedToEdge="true" type="emerald_block" height="1"/>
<EndBlock fixedToEdge="true" type="''' + END_BLOCK + '''" height="1"/>
<SubgoalBlock type="''' + GOAL_BLOCK + '''" height="1"/>
<PathBlock type="''' + PATH_BLOCK + '''" colour="WHITE ORANGE MAGENTA LIGHT_BLUE YELLOW LIME PINK GRAY SILVER CYAN PURPLE BLUE BROWN GREEN RED BLACK" height="1"/>
<FloorBlock type="''' + FLOOR_BLOCK + '''" height="1"/>
<OptimalPathBlock type="stone" variant="smooth_granite andesite smooth_diorite diorite"/>
<GapBlock type="'''+ GAP_BLOCK + '''" height="1"/>
<AddQuitProducer description="finished maze"/>
</MazeDecorator>
'''
def __init__(self, agent=None, maze_str=None):
if (not(maze_str is None)):
self.__maze_str = maze_str
else:
self.__maze_str = MazeSimRL.DEFAULT_MAZE
self._agent = agent
# -- set up the python-side drawing -- #
(canvas, root) = self.setup_table_gfx()
if (self._agent is None):
actionSet = ["movenorth 1", "movesouth 1", "movewest 1", "moveeast 1"]
self._agent = QLAgent(
actions=actionSet,
epsilon=0.01,
alpha=0.1,
gamma=1,
debug = False,
canvas = canvas,
root = root)
def get_mission_xml(self):
return '''<?xml version="1.0" encoding="UTF-8" ?>
<Mission xmlns="http://ProjectMalmo.microsoft.com" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance">
<About>
<Summary>Run the maze!</Summary>
</About>
<ModSettings>
<MsPerTick>''' + str(MazeSimRL.MS_PER_TICK) + '''</MsPerTick>
</ModSettings>
<ServerSection>
<ServerInitialConditions>
<AllowSpawning>false</AllowSpawning>
</ServerInitialConditions>
<ServerHandlers>
<FlatWorldGenerator generatorString="3;7,220*1,5*3,2;3;,biome_1" />
''' + self.__maze_str + '''
<ServerQuitFromTimeUp timeLimitMs="45000"/>
<ServerQuitWhenAnyAgentFinishes />
</ServerHandlers>
</ServerSection>
<AgentSection mode="Survival">
<Name>RL Smart Guy</Name>
<AgentStart>
<Placement x="1" y="81" z="1"/>
</AgentStart>
<AgentHandlers>
<VideoProducer want_depth="false">
<Width>640</Width>
<Height>480</Height>
</VideoProducer>
<ObservationFromFullStats/>
<DiscreteMovementCommands />
<RewardForMissionEnd>
<Reward description="found_goal" reward="100" />
<Reward description="out_of_bounds" reward="-1000" />
<Reward description="hot_fire" reward="-100" />
</RewardForMissionEnd>
<RewardForTouchingBlockType>
<Block type="gold_block" reward="3" />
<Block type="stone" reward="4" />
<!-- <Block type="diamond_block" reward="100" behaviour="onceOnly" />
<Block type="grass" reward="-1000" behaviour="onceOnly" />
<Block type="lava" reward="-100" behaviour="onceOnly" /> -->
</RewardForTouchingBlockType>
<RewardForSendingCommand reward="-2"/>
<AgentQuitFromTouchingBlockType>
<Block type="diamond_block" description="found_goal" />
<Block description="out_of_bounds" type="grass" />
<Block description="hot_fire" type="lava" />
</AgentQuitFromTouchingBlockType>
</AgentHandlers>
</AgentSection>
</Mission>'''
def setup_table_gfx(self):
scale = 50
world_x = MazeSimRL.MAP_SIZE
world_y = MazeSimRL.MAP_SIZE
root = tk.Tk()
title = str(type(self._agent)) + "-table"
root.wm_title(title)
canvas = tk.Canvas(root, width=(MazeSimRL.MAP_SIZE-1)*scale,
height=(MazeSimRL.MAP_SIZE-1)*scale, borderwidth=0, highlightthickness=0,
bg="black")
canvas.grid()
root.update()
return (canvas, root)
def run_sim(self, exp_role, num_episodes, port1, serv1, serv2, exp_id, epi, rsync):
if (self._agent is None):
print("Need to set an agent!")
return
env = malmoenv.make()
env.init(self.get_mission_xml(),
port1, server=serv1,
server2=serv2, port2=(port1 + exp_role),
role=exp_role,
exp_uid=exp_id,
episode=epi,
resync=rsync,
action_space = malmoenv.ActionSpace(self._agent.get_actions() + ["move 0"]))
expID = 'tabular_RL'
for i in range(num_episodes):
cumulative_rewards = []
print("Reset [" + str(exp_role) + "] " + str(i) )
movements = None
env.reset()
num_steps = 0
sim_done = False
total_reward = 0
total_commands = 0
#--- Dummy step so that we get some initial info from the environment ---#
(obs, reward, sim_done, info) = env.step(4)
time.sleep(0.01)
#------#
cumulative_reward = self._agent.run(env, info, reward)
print("Cumulative reward: %d" % cumulative_reward)
cumulative_rewards += [ cumulative_reward ]
print("Done.")
print("Cumulative rewards for all %d runs:" % num_episodes)
print(cumulative_rewards)
# Setup our Maze and run it
if __name__ == '__main__':
parser = argparse.ArgumentParser(description='malmovnv test')
parser.add_argument('--port', type=int, default=9000, help='the mission server port')
parser.add_argument('--server', type=str, default='127.0.0.1', help='the mission server DNS or IP address')
parser.add_argument('--server2', type=str, default=None, help="(Multi-agent) role N's server DNS or IP")
parser.add_argument('--port2', type=int, default=9000, help="(Multi-agent) role N's mission port")
parser.add_argument('--episodes', type=int, default=2000, help='the number of resets to perform - default is 1')
parser.add_argument('--episode', type=int, default=0, help='the start episode - default is 0')
parser.add_argument('--resync', type=int, default=0, help='exit and re-sync on every N - default 0 meaning never')
parser.add_argument('--experimentUniqueId', type=str, default="tabular_RL", help="the experiment's unique id.")
args = parser.parse_args()
if args.server2 is None:
args.server2 = args.server
my_sim = MazeSimRL()
my_sim.run_sim(0, args.episodes, args.port, args.server, args.server2,
args.experimentUniqueId, args.episode, args.resync)
